The Quadro P600 was a professional graphics card by NVIDIA, launched on February 7th, 2017. Built on the 14 nm process, and based on the GP107 graphics processor, the card supports DirectX 12. The GP107 graphics processor is an average sized chip with a die area of 132 mm² and 3,300 million transistors. Unlike the fully unlocked GeForce GTX 1050 Ti, which uses the same GPU but has all 768 shaders enabled, NVIDIA has disabled some shading units on the Quadro P600 to reach the product’s target shader count. It features 384 shading units, 24 texture mapping units, and 16 ROPs. NVIDIA has paired 2,048 MB GDDR5 memory with the Quadro P600, which are connected using a 128-bit memory interface. The GPU is operating at a frequency of 1329 MHz, which can be boosted up to 1557 MHz, memory is running at 1002 MHz (4 Gbps effective).
Being a single-slot card, the NVIDIA Quadro P600 does not require any additional power connector, its power draw is rated at 40 W maximum. Display outputs include: 4x mini-DisplayPort 1.4a. Quadro P600 is connected to the rest of the system using a PCI-Express 3.0 x16 interface. The card measures 150 mm in length, 69 mm in width, and features a single-slot cooling solution.

Memory Size

2 GB

Memory Type

GDDR5

Memory Bus

128 bit

Bandwidth

80.13 GB/s

Base Clock

1266 MHz

Boost Clock

1354 MHz

Memory Clock

1252 MHz
5 Gbps effective
